Lankoforce®HS with Polyester Jacket

Lankoforce®HS is a new presentation of the Lankoforce® line. With a 12 braids Lankoforce® core and three types of coatings at choice it positions itself as the ideal option in applications where a high breaking load, low weight and high resistance to abrasion are essential.

The Polyester jacket is a durable jacket with excellent abrasion and heat resistance but with non-floating properties.

Diameter (mm)	Weight (g/m)	MBF (kN)	MBF (tf)
14	113	105	10,7
16	156	149	15,2
18	221	200	20,4
20	261	267	27,2
22	310	332	33,9
24	350	409	41,7
26	426	492	50,2
28	490	583	59,5
30	558	670	68,4
32	645	767	78,3
34	732	863	88,1
36	814	970	99,0
38	892	1084	111
40	970	1177	120
42	1040	1303	133
44	1220	1544	158
48	1390	1782	182
50	1476	1923	196
52	1640	2141	218
56	1950	2283	233
60	2210	2635	269
64	2480	2983	304
68	2860	3508	358
72	3190	3938	402

Properties

MaterialCore: Dyneema® - Jacket: Polyester Chemical resistanceGood Specific gravity1.06 Breaking load (wet)100% Abrasion resistanceVery Good UV resistanceExcellent Water absorption0% Construction12 strands braided with Polyester jacket Melting pointCore: ± 147 °C - Jacket: ± 265 °C TCLL value100 %ColourYellow MarkersOrange

Applications

Bottom Trawling

Flyline

Lifeline

Ripline

Trawl Warps

Pelagic Trawling

Frame Ropes

Round Straps

Trawl Warps
